Pulse is a professional battery-powered tile vibrator designed for working with tiles and large-format slabs. It ensures perfect adhesive coverage between the tile and the surface. The corner beating plate is included only with item 11501/1.
Pulse
Description
Description
CARRYING CASE
- Practical carrying case for comfortable and safe transport, included.
- Working surface extender, included.
PICK AND PLACE
Equipped with an efficient suction cup and a practical lever for ultra-fast “Pick & Place”.
(Maximum 25 kg per tile)
INTENSITY LEVEL
Press the white rubberized button on the handle. The vibration intensity levels are adjusted by a dial.
BEATING PLATE
Specifically shaped corner beating plate for easy reach into corners. Inspired by the classic MiniVibro model produced by Battipav in the 1970s.
Scheda Tecnica
Pulse
| PULSE VIBRATORE MANUALE A VENTOSA CON PIASTRA | PULSE VIBRATORE MANUALE A VENTOSA | |
| Dimensioni prodotto assemblato | 410 x 130 x 135 mm | 410 x 130 x 135 mm |
| Dimensione piastra | 200 x 300 x 8 mm | Non equipaggiato |
| Dimensione ventosa | Ø 130 mm - spessore 7 mm | Ø 130 mm - spessore 7 mm |
| Capacità massima di carico | 25 kg | 25 kg |
| Voltaggio | 18 V | 18 V |
| Intensità di corrente | 2 Ah | 2 Ah |
| Tensione motore | 18 V Dc | 18 V Dc |
| Corrente assorbita | 2 Ah | 2 Ah |
| Tempo di ricarica | 160 MIN | 160 MIN |
| Potenza disponibile | 36 Wh | 36 Wh |
| RPM (vibrazioni) | min. 500 - max. 12.000 | min. 500 - max. 12.000 |
| Machine weight | 2,2 kg | 1,6 kg |
